Wireless Adapter Split Air Conditioner Control Zigbee IR Controller Smart Air Conditioner Controller
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
WiFi Smart Home Programmable Thermostat Alexa Touch Screen Thermostat
-
Thermostat wifi alexaProgrammable Alaxa Google Home HVAC Touchscreen Smart Home Thermostat WiFi
-
ZigBee Home Automation IR Blaster Smart Air Conditioner Controller
-
ZigBee Smart Home Automation smart ac controller Temperature Control Thermostat IR Split AC Controller
-
Wireless Adapter Split Air Conditioner Control Zigbee IR Controller Smart Air Conditioner Controller
-
Google Home HVAC Programmable Touchscreen Room Thermostat Wifi
Product Description
Product Description
Product Name | Zigbee IR Controller |
Material | ABS Plastic |
Wireless Connectivity | ZigBee 2.4 GHz IEEE 802.15.4 |
RF Characteristics | Operating frequency: 2.4GHz Internal PCB Antenna Range outdoor/indoor:100m/30m TX Power: 6~7mW (+8dBm) Receiver sensitivity: -102dBm |
ZigBee Profile | Home Automation Profile |
IR | Infrared emission and receiving Angle: 120° angle covering Carrier Frequency: 15kHz-85kHz |
Temperature Sensor | Measuring Range: -10-85°C |
Working Environment | Temperature: -10-55°C Humidity: up to 90% noncondensing |
Power Supply | Direct plug-in: AC 100-240V (50-60 Hz) Rated power consumption: 1W |
Dimensions | 66.5 (L) x 85 (W) x 43 (H) mm |
Weight | 116 g |
Mounting Type | Direct Plug-in Plug Type: US, AU, EU, UK |
Wireless Adapter Split Air Conditioner Control Zigbee IR Controller
The Split A/C control AC201-A converts the home automation gateway’s ZigBee signal into an IR command so as to control the air conditioner,TV, Fan or other IR device in your home area network. It has pre-installed IR codes used for main-stream split air conditioners and offers study functionality use for other IR devices.
Details Images
Wireless Adapter Split Air Conditioner Control Zigbee IR Controller
Product Usage
Main Features
* Converts home automation gateway’s ZigBee signal into IR command so as to control the air conditioner,TV, Fan or other IR device in your home area network
* Pre-installed IR code for main stream split air conditioners
* IR code study functionality for unknown brand IR devices
* One-click pairing with remote control
* Supports up to 5 air conditioners with pairing and 5 IR remote controls for learning.Each IR control supports learning with five button functions
* Switchable power plugs for various country standards: US, AU, EU, UK
* Pre-installed IR code for main stream split air conditioners
* IR code study functionality for unknown brand IR devices
* One-click pairing with remote control
* Supports up to 5 air conditioners with pairing and 5 IR remote controls for learning.Each IR control supports learning with five button functions
* Switchable power plugs for various country standards: US, AU, EU, UK
