Hot Sale salt vibrate fluid bed dryer for wholesale

1. what is the principle of vibrate fluid bed dryer?

The vibrate fluid bed dryer adopts PLC intelligent digital display to realize intelligent preheating, feeding, automatic temperature control, uniform vibrate shifting materials, automatic air intake, automatic moisture removal, automatic separating, automatic discharging and other operating procedures. The blower transfers the filtered air into the air heater, and the heated hot air enters the lower tank of the main machine, and the material enters the fluid bed from the feed inlet, and the air is blown vertically from the bottom to the top through the distribution plate of the fluid bed. The material is boiling. The main machine generates directional uniform vibrating under the excitation force of the vibrate motor, so that the material is thrown horizontally, and the dried material forms a fluidized state under the combined action of the above-mentioned hot air flow and machine vibration, so that the material and The hot air has a long contact time and a large area, so that a high-efficiency drying effect is obtained. The moisture formed on the upper chamber of the main machine is extracted by the induced draft fan, and the material contained in the humid air is recovered by the cyclone separator or the bag filter, and the humid air is discharged into the atmosphere through the induced draft fan, and the dried material is discharged from the discharge port.

2. what is the Features of vibrate fluid bed dryer?:

• The vibration created by motor is stable in operation and convenient in maintenance, low noise and long life.

• High effection,raw material is heates evenly and heated evenly and heat exdhange is fully used and dry capacity is high. Compared with ordinary drier, the energy can be saved about 30%.

• It is good in regulation and wide in suitablity. The thickness of raw material layer and movable speed inside the maching and the amolitude can be adjusted through continous variable speed.

• It is small for damaging the surface of raw material. The equipment can be used for drying raw materials that are easy broken. The drying effect can not affected even if raw materials have irregular shape.

• A fully enclosed structure, effectively prevent the material and the air space between the cross infection of the working environment clean.

• You can string multi-srt to raise capacity of raw materials, if the raw material contain high moisture such as polyacrylamide.

3. what is the Vibrate fluid bed dryer applied for?

It is suitable for drying and cooling of powdery and granular materials in chemical, pharmaceutical, food, dehydrated vegetables, grain, minerals and other industries.

4.  what is the configuration of vibrate fluid bed dryer?

The vibrate fluid bed dryer is mainly composed of the main engine box ( the inlet, the upper cover, the outlet, the lower case, the vibrate motor, the air inlet, the observation window, the punching plate and the discharge port, etc.) , heating system (heat source required for hot air, support for coal, oil, gas, steam, electricity and other programs), cyclone separate system, dust removal and drainage system, PLC intelligent control system.
