FX3UC-16MR/DS-T Mitsubishi Clone Continuous Electrical Apparatus Plc

Guangzhou Hongsen Servo Motor Co., Ltd.
FX3UC-16MR/DS-T Mitsubishi Clone Continuous Electrical Apparatus Plc thumbnail-1
FX3UC-16MR/DS-T Mitsubishi Clone Continuous Electrical Apparatus Plc photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2005
Annual Export Value:
US$1 Million - US$1.5 Million
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Product Description

Mitsubishi Electric
Melsec iQ-F Series
iQ Platform-compatible PLC FX3UC

Designed on the concepts of outstanding performance, superior drive control an user centric programming, Mitsubishi's MELSEC-F Series has been reborn as the MELSEC iQ-F Series.
From stand alone use to networked system applications, MELSEC iQ-F Series brings your business to the next level of industry.
Advanced Built-in Functions
CPU Performance
Built-in Analog Input/Output (with alarm output)
Built-in SD Card Slot
RUN/STOP/RESET Switch
Built-in RS-485 Port (with MODBUS function)
Security
High-speed System Bus Communication
Built-in Ethernet Port
Battery-less and Maintenance-free
Advanced positioning function
Built-in Positioning (200 Kpps, 4-Axis built-in)
Simple Motion Module (4-Axis control module)
Advanced Motion Control
User-friendly programming software GX Works3

Specification
Model :
FX3UC-16MR/DS-T
FX5U-32MR/ES
Power Supply:
Power supply from CPU module
CPU module
Total No.
of points
8 points
No. of input/output points & Input/output type
Input
8 points
24 V DC internal current
consumption
24 V DC
Transistor (sink)
Selecting the FX5UC Model
Type
Details
Connection details, model selection
CPU module
PLC with built-in CPU, power supply,input/output and program memory.
Various expansion devices can be connected.
I/O module
Product for expanding I/O. Some products are powered.
Input/output can be expanded to up to 256 points. (Expansion module: Max. 16 modules (excluding extension power supply module)).The total with CC-Link remote input/output is max. 512 points.
FX5 extension power supply module
Module for expanding power supply if CPU module’s internal power supply is insufficient. Extension cable is enclosed.
Power can be supplied to I/O module, intelligent function module, and bus conversion module. Up to 2 modules can be connected.
I/O module
Product for expanding I/O. Some products are powered.
Input/output can be expanded to up to 256 points. (Expansion module: Max. 16 modules (excluding extension power supply
module)).The total with CC-Link remote input/output is max. 512 points.
FX5 intelligent function module
Module with functions other than input/output.
Up to 16 expansion modules including the I/O module can be connected (excluding the extension power supply module).
Bus conversion module
Conversion module for connecting FX3 Series expansion module.
FX3 Series expansion module can be connected only to the right side of the bus conversion module
FX5 expansion board
Board connected to front of CPU module to expand functions.
Up to 1 module can be connected to the front of the CPU module. (Expansion adapter can also be used.)
FX5 expansion adapter
Adapter connected to left side of CPU module to expand functions.
Up to 6 modules can be connected to the left side of the CPU module
FX3 extension power supply module
Module for expanding power supply if CPU module’s internal power supply is insufficient.
The bus conversion module is required for use. Up to 2 modules can be connected.
FX3 intelligent function module
Module with functions other than input/output.
The bus conversion module is required for use. When using the FX3 extension power supply module, up to 8 modules 4 can be used.When not using the FX3 extension power supply unit, up to 6 modules 4 can be used.
Model options

FX3UC CPU Modules
FX3UC-96MT/D
FX3UC-64MT/D
FX3UC-32MT/D
FX3UC-16MT/D
FX3UC-96MT/DSS
FX3UC-64MT/DSS
FX3UC-32MT/DSS
FX3UC-16MT/DSS
FX3UC-32MT-LT

FX3UC Expansion Adapters
Communication
FX5-232ADP
FX5-485ADP
Analog
FX5-4AD-ADP
FX5-4DA-ADP
FX3UC Expansion Boards
FX5-232-BD
FX5-485-BD
FX5-422-BD-GOT
Powered I/O Modules
FX5-32ER/ES
FX5-32ET/ES
FX5-32ET/ESS

Unpowered I/O Modules
FX5-8EX/ES
FX5-16EX/ES
FX5-8EYR/ES
FX5-8EYT/ES
FX5-8EYT/ESS
FX5-16EYR/ES
FX5-16EYT/ES
FX5-16EYT/ESS
Intelligent Function Modules
FX5-40SSC-S
Extension Power Supply Module
FX5-1PSU-5V
Bus Conversion Module
FX5-CNV-BUS
Battery
FX3U-32BL

SD card
NZ1MEM-2GBSD (2 GB)
NZ1MEM-4GBSD (4 GB)
Programming software
GX Works3
Extension Power Supply Module
FX3U-1PSU-5V



Intelligent Function Modules
Analog
FX3U-4AD
FX3U-4DA
Positioning
FX3U-1PG
Network
FX3U-64CCL
FX3U-16CCL-M
Temperature control
FX3U-4LC
High Speed counter
FX3U-2HC
Packing & Delivery
Packing Details : 1pcs/carton
Delivery Details : 1-2 days after order confrimed
