BERGQUIST SIL PAD TSP PPK900, Polyester-Based, Thermally Conductive Insulation Material
BERGQUIST SIL PAD TSP PPK900 Known as BERGQUIST POLY-PAD K-4
BERGQUIST POLY-PAD K-4 is a composite of film coated with a polyester resin.
BERGQUIST PPK4 is an economical insulator and the film carrier provides excellent dielectric and physical strength.Polyester-based, thermally conductive insulators from Henkel provide a complete family of material for silicone-sensitive applications. SIL PADS are ideally suited for applications requiring conformal coatings or applications where silicone contamination is a concern
(telecom & certain aerospace applications). SIL PADS are constructed with ceramic-filled polyester resins coating either side of a
fiberglass carrier or a film carrier. The SIL PAD family offers a complete range of performance characteristics to match individual
applications.Options and ConfigurationsStandard thickness - 0.006"Custom made configurations available upon request.
