2.0 Ton Mini Excavator
Product Description
|
Model |
MAP20 |
|
Operating Weight |
2000kg |
|
Digging bucket capacity |
0.05cbm/500kg |
|
Digging bucket width |
420mm, can add narrow bucket is 200mm |
|
Engine |
Yanmar (3TNV70-S) |
|
Rated power |
10kw/2200/r/min |
|
Displacement |
0.854L |
|
Bore stroke |
three cylinder, water cool |
|
Main pump |
JAPAN NAICH |
|
Pump flow |
23.3L/Min |
|
Hydraulic oil tank capacity |
15.3L |
|
Engine oil tank capacity |
2.8(1.3)L |
|
Diesel tank capacity |
19 L |
|
Valve |
JAPAN KYB |
|
Displacement |
6.8ml/r |
|
Swing motor |
EATON |
|
Traveling motor |
|
|
MAIN DEMENSIONS |
|
|
Overall dimension( LxWxH) |
|
|
Total length of track on land |
1590mm |
|
Platform ground clearance |
473 mm |
|
Platform back turning radius |
740 mm |
|
Chassis width |
990 mm(retract)/ 1240mm(extended) |
|
Track width |
230 mm |
|
Chassis ground clearance |
460 mm |
|
Bucket digging force |
13.5kn |
|
Arm digging force |
10.1kn |
|
Theoretical Maximum traction |
17.5Kn |
|
Ground specific pressure |
32.8KPA |
|
Track height |
360 mm |
|
Swing boom to left |
390 mm |
|
Swing boom to right |
510 mm |
|
OPERATING RANGE |
|
|
Max. Digging depth |
2150 mm |
|
Max. Vertical digging depth |
1740 mm |
|
Max. Digging height |
3275 mm |
|
Max. Dumping height |
2310 mm |
|
Max. Digging radius on ground |
3610 mm |
|
Min. Rotation radius |
1580 mm |
|
Max. Upgrade height of bulldozer blade |
275 mm |
|
Max. Digging depth of bulldozer blade |
180 mm |
Packaging & Shipping
Certifications
FAQ
1.How can I place order?1.How can I place order?
A: You can contact us by email about your order details, or place order on line.
2.How can I pay you?
A: After you confirm our PI, we will request you to pay. T/T or start order from Alibaba trade assurance
3. Are you factory supplier?
A: Yes, we are real factory supplier for over10years, own a super technical team to serve adjusting design for customers
4. How do you take care when your clients received defective products?
A: replacement. If there are some defective items,
we usually credit to our customer or replace in next shipment.
5.How do you check all the goods in the production line?
A: We have spot inspection and finished product inspection.
We check the goods when they go into next step production procedure.
6. What's the order procedure?
A: First we discuss order details, production details by email or TM.Then we issue you a PI for your confirmation.You will be requested to do prepaid full payment or deposit before we go into production.After we get the deposit, we start to process the order.We usually need 7-15 days if we don't have the items in stock.Before production has been finished,we will contact you for shipment details, and the balance payment.After payment has been settled, we start to prepare the shipment for you.
More details please ask us online or send inquiry to us,we will answer first time.
