High efficiency 180HP crawler bulldozer SEM818D LGP New Model
Products Description
1.The high reliability power shift transmission and the two-stage final drive with spur gear reducing structure and splash
lubrication feature high durability and high operating efficiency.
2.The closed system is adopted to maintain the water tank pressure at specific value and the forced air supply can enhance the cooling effect.
3.The harnesses of whole machine are protected by seamless corrugated tubes to improve the reliability of electric harnesses.
4.The integrally injection molded instrument panel integrates the A/C, electric devices, and instrument box, featuring beautiful appearance and high grade.
5.The optimized working lamp arrangement improves the lighting performance of vehicle.
6.The reversing alarm and the working warning lamp are added to provide the safety warnings during working.
7.The full box-type main frame features high carrying capacity against impact load and bending moment and the high quality welds
guarantee the life cycle of the main frame.
Specification
Model
816
816 LGP
822
822LGP
Operating Weight
17230kg
19720kg
23680kg
25400kg
Ground Pressure
68 kPa
31.5 kPa
70 kPa
39 kPa
Ground Clearance
410 mm
435 mm
394 mm
394 mm
Max. Slope
30°
30°
30°
30°
Engine
Model
Weichai WD10G178E25
Weichai WD10G178E25
Weichai WD12G240E26
Weichai WD12G240E26
Flywheel Power
120Kw/160Hp
120Kw/160Hp
162Kw/220Hp
162Kw/220Hp
Work Tool
Blade Type
SU
S
SU
S
Blade Capacity
4.3 m³(S 3.4 m³)
3.4 m³
6.4 m³(U 7.5 m³)
5.5 m³
Blade Width
3140 mm(S 3490 mm)
4227 mm
3720 mm(U 4015 mm)
4617 mm
Blade Height
1240mm(S 1165 mm)
1000 mm
1511 mm
1345 mm
Max.Blade Lift Ground Clearance
1041 mm
1055mm
1140mm
1165mm
Max. Blade Digging Depth
430mm
470mm
563mm
600mm
Max.Output Rimpull
280KN
280KN
350KN
350KN
Maximum Clearance Under Tip
615mm
N/A
640mm
N/A
Maximum Digging Depth Of Ripper
584mm
N/A
650mm
N/A
Powertrain
Type
Electric control,Dual-path,Hydrostatic Drive
Travel Speed-F/R
0-10km/hr(Infinitely Variable Speed Control)
0-11.5km/hr(Infinitely Variable Speed Control)
Streeing & Brake
Hydrostatic Streeing,Wet,Multiple-Disc Brakes
Minimum Streeing Radius
3610mm
3740 mm
4225mm
4300mm
Undercarrige
Track Shoe Width
510mm
1050mm
560mm
915mm
Track Shoe Quantity
37 piece
42 piece
40 piece
45 piece
Length Of Track On Ground
2430mm
2925mm
2948mm
3488mm
Track Gauge
1880mm
2300mm
2000mm
2340mm
Track Roller Quantity
6/Side
7/Side
7/Side
8/Side
Carrier Roller Quantity
2/Side
2/Side
2/Side
2/Side
Hydraulic System
Type
Pilot Control
Implement Hydraulic System Pressure
19 Mpa
Service Refill Capacities
Cooling System
45L
Hrdrostatic Oil
40L
62L
Implement Oil
60L
110L
Fuel
320L
460L
Pivot Shaft Case(Eash side)
1.2L
0.8L
