Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Excavator > Brand New Mini Excavator 6 Ton 0.23 M3 Small Crawler Excavator
Brand New Mini Excavator 6 Ton 0.23 M3 Small Crawler Excavator
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
2004
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
9 Tons Front End Loader Lw900Kn With Factory PriceNegotiableMOQ: 1 -
China 5M3 Bucket Front End Loader 9 Ton 5T Front End Loader 5 Tons Wheel LoaderNegotiableMOQ: 1
-
High Quality Wheel Loader Payloader 9 Ton Back Hoe Loader Cheap BackhoeNegotiableMOQ: 1
-
9 Ton Wheel Loader In Ecuador China Brand 2 Ton Mini Wheel Loader Lw200KvNegotiableMOQ: 1
-
China Zl-940 5 Ton Articulated Loader CLG856H Small Mini Front End Wheel Loader 4WdNegotiableMOQ: 1
China LOVOL FR65E 6.2ton excavator low price
Contacts
Candice Ouyang
Wechat:18779902186
Mobile,Whatsapp: +86-187-7990-2186
QQ: 2459419509
Features
1. Original engine, meeting China’s third-stage emission standards, strong power, high fuel economy.
2. Exclusive three-pump throttling system, intelligent confluence and regeneration with 8% torque increase and 6% fuel consumption decrease.
3. Large passage main valve, large diameter pipeline, optimized pipeline direction, low pipeline friction loss, and reduce the energy loss of the hydraulic system by 5%.
4. Various work devices for various operating conditions(Optimized bucket shape, high loading/unloading efficiency)
Parameters
| Main Parameters | 6090*1950*2660 |
|---|---|
| Operation Weight (Standard Configuration) (kg) | 5730 |
| Standard Bucket Capacity | 0.18 |
| Transport Dimensions(mm) | 6090*1950*2660 |
| Bucket Breakout Force (KN) | 42 |
| Stick Breakout Force (KN) | 31 |
| Maximum Traction (KN) | 50.5 |
| Device | |
| High-low Speed (Km/h) | 4.2/2.5 |
| Climbing Performance(°) | 35 |
| Total Length of the Crawler | 2550 |
| Tail Turning Radius (mm) | 1700 |
| Width of the Crawler | 400 |
| Ground Pressure (Kpa) | 32.33 |
| Turning Mechanism | |
| Turning Speed (rpm) | 10.2 |
| Engine | |
| Model | 4TNV94L |
| Type | Four Cylinders, Direct Injection, Naturally Aspirated, Water-cooling |
| Rated Power/Rotate Speed (KW/rpm) | 36.2/2100 |
| Rated Torque/Rotate Speed (N.m/rpm) | 198/1400 |
| Cylinder Diameter*Stroke (mm) | 94*110 |
| Output Value (L) | 3.054 |
| Fuel Consumption (g/KW.h) | 247 |
| Fuel Tank Capacity (L) | 120 |
| Hydraulic System | |
| Main Pump Pressure (Mpa) | 24.5 |
| Main Pump Flow | 135*2 |
| Operating Scope | |
| Maximum Digging Height (mm) | 5170 |
| Maximum Dumping Height (mm) | 3500 |
| Maximum Digging Depth (mm) | 3925 |
| Maximum Digging Radius (mm) | 6110 |
