ZOOMLION Brand New Small 12 Ton Truck Crane ZTC121V462-1/ZTC121V Hot Sale

4-section U-shaped boom, full extension 31.1m, the maximum lifting moment of the basic arm is 515knm, and the maximum lifting moment of the full extension arm is 295knm.

High compression ratio Weichai engine + Fa-st 8-speed synchronous gearbox + high speed ratio drive axle, strong power. The outrigger spans 5.8m, the longitudinal span is 4.7m, and the counterweight is 1.2 tons.

The maximum lifting capacity of the full outrigger is 4.3 tons. The maximum speed of the whole machine is 85km/h, and the minimum turning diameter is 17.5m.

Total mass in driving state: 16510kg
Front axle axle load: 5510kg
Rear axle axle load: 11000kg
Dimensions (length, width and height): 11200x2500x3320mm
Engine model: WP4.6NQ220E61A
Power: 162/2300kw/rpm
Emissions: EURO VI
Fuel consumption per 100 kilometers: 26L
Maximum driving speed: 85km/h
Maximum grade: 45%
Minimum turning diameter: 17.5m
Minimum ground clearance: 255mm
Braking distance: 10m (vehicle speed 30km/h)
Maximum rated lift: 12000kg
Main boom: boom length/maximum lifting height: 31.1/31.4m
