Product Description
HW85 Wheel Excavator
* 1.Electrical system: Equipped with color liquid crystal display, with self-test, monitoring, emergency fault alarm, goodhuman-computer interaction, high-configuration electrical control software, higher reliability.
* 2. Power system: The advanced turbocharged exhaust engine has sufficient power reserves to maximize the power of the engine, achieve perfect matching and reduce power loss.
* 3.Hydraulic system: Imported international famous brand hydraulic parts, small power loss, fast action, good coordination of compound action, high efficiency and energy saving, high reliability and long service life.
* 4. Traveling system: using heavy-duty front and rear drive axles and gearboxes to provide higher carrying capacity.
* 5. Cab: The new cab has a new interior design, wide vision, spacious and bright, humanized front gear mechanism, equipped with high-grade adjustable suspension seats, silicone oil shock absorption, and superior driving environment.
* 6. Cooling system: adopts parallel cooling installation method, easy to clean and install and remove, and has high cooling efficiency.
Wheel type 75 8t ton mini excavator with quick change connector
Technical parameter of HW85 wheel excavator | ||
Engine | ||
Model | YC4FA65-T300 | |
Output Power | 48kw/2200rpm | |
Dimensions | ||
Shipping Length（mm） | 6600 | |
Shipping Height（mm） | 2900 | |
Overall width（mm） | 2180 | |
Weight（kg） | 8400 | |
Tail Rdius （mm） | 1850 | |
Wheel tread （mm） | 1660 | |
Wheelbase（mm） | 2360 | |
Min Ground Clearance(Transmission case)（mm） | 310 | |
Height of cab from the ground（mm） | 2960 | |
Boom length（mm） | 3800 | |
Arm length（mm） | 2000 | |
Maximum opening width of gripper（mm） | 1250 | |
Minimum opening width of gripper（mm） | 55 | |
Rotating angle of gripper（°） | 360 | |
Working Range & Dig force | ||
Maximum snatch height （mm） | 7900 | |
Maximum unloading height（mm） | 5300 | |
Maximum working range（mm） | 7380 | |
Minimum Swing Radius （mm） | 2785 | |
Maximum radius grab weight（Kg） | 500 | |
Maximum travelling speed（km/h） | 24 | |
