Food Grade Stainless Steel Sanitary Sansun Pneumatic Manual Reversing Divert Valve with Weld Ends

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Description

Product Overview

Product Name:

Food Grade Stainless Steel Sanitary Sansun Pneumatic Manual Reversing Divert Valve with Weld Ends

Valve Body Material:

1.4435/1.4301, SS304/SS316L(Forged)

Seal Material:

EPDM (standard)

Surface Finishing

Mechanically polishing , Sand blasted

Operating Principles:

Single Seat Valve is operated by single acting or double acting pneumatic actuator, the air push valve shaft move to on and off position.This valve is hygienic design,applied to all kinds of,food processing,drink,and pharmaceutical industry.

Max Working Pressure:

10Bar/145 PSI

Max. Working Tem.:

140 degree C

Air Pressure:

5-7 bar G1/8"(BSP)

Availably Size:

DN25-DN100,1"-4"

Features

EN10204-3.1 B Mill cert is offered

PED 2014/68/EU

The valve body can be changeable with any kind of connection

Availably standard:

DIN/SMS/RJT/ISO/IDF

Operated:

Pneumatic

Options

Gasket: EPDM, silicone or Viton

Connection:weld,clamp,thread,

Control:

Sensor, Pneuamtic actuator(single acting, double acting), electric actuato, C-TOP, C-top controller(AS-I)

Certificate:

PED 2014/68/EU

Application scope:

Dairy,food, beverage, pharmacy, cosmetic, Chemical, etc

Product Show

Sanitary Valve

Butterfly Valves

Check Valves

Ball Valvess
Single Seat Valve/Mixproof valve

DiaphragmValves
Sample Valves

Pressure Relief Safety Valves
Three Way Plug Valve
Angle Seat Valve

BrewHardware

Brewing Fittings

Vaccume Air Released Valve
Pressure Relief Valve
Sampling Valve
Foam Eliminator
Carbonation Stone

Tank & Accessories

Manhole Cover/Manway

Tank Cleaning Ball
Sight glass
Filter Strainer
Stainless steel Tank
Stainless Steel Carbonation Stone
Bunging Device
Sampling Valve with Coil for Beer
Beer Foam Eliminator

Sanitary Pumps

Centrifugal PumpFood Transfer Pump
Rotary Lobe Pump
Self Priming CIP Pump
Single Screw Pump
Emulsifying pump

Tube & Pipe fittings

Elbow/Tee/Reducer/CrossClamp & Ferrule
DIN/SMS/RJT/IDF Unions
Flanges
Weld Pipe & Square Tube
Vacuum Fittings

Gasket & Spare Seals

Silicone/EPDM Gasket For Triclamp Silicone/EPDM Gasket For Union
Silicone/EPDM/Viton seal For Valve
Teflon seat For Ball valve
Mechanical Seal for Pump
Membrane for aseptic Valve

FAQ

Q: DO YOU HAVE MILL TEST CERTIFICATE?

Yes, Each order is traceable by Material certificate EN10204 3.1, and we can also offer pressure testing report, roughness test report if Client need.

Q: DO YOU HAVE PRODUCT WARRANTY

Yes,12 months warranty. 100% inspection on finished products before dispatch. Inferior products can be returned or replaced.Repair parts is supplied for replacement.

Q: WHAT'S THE MOQ?

No MOQ for standard products. Customized products can be discussed.

Q: MAY I HAVE FREE SAMPLES?

Free samples can be provided for starting cooperation, Freight is collected by Client.

Q: HOW LONG IS THE DELIVERY TIME?

Standard item are in stocked--Normally 3-5 days. Bulk order usually takes about 20-25 days.

Q: WHY WOULD I CHOOSE YOU?

1.Hard-working labor worker and advanced machine ensure large production capacity. It will give our clients fast delivery time.

2. Professional engineer and designer ensure the product parameter is well manufatcured and every month, we will have new products to help our client's enlarge market.

3. 100% inspection on finished products before dispatch, give our clients good quality products.

4. High effective sales team quick response to any quote and complaint.

Product packaging

Our Company

Wenzhou Sansun stainless Co., Ltd. Was founded in 2012, Located in Wenzhou, China, is a professional manufacturer integrating design, production, sales and service.

Our products includes: Sanitary valve, Sanitary pipe fittings, Sanitary pump,Tank accessories, Closed Loop Extractor, etc.

All kinds of non-standard products are customized according to the requirements of customers. Products can be traced back to the manufacturing and time of each process to ensure the quality of products.

We have skillful production people and strong R&D technicians who have over 15 years experience in manufacturing, developing and designing various sanitary Valves & fittings. Under the strict control system - ISO 9001 quality assurance, we have made our OEM products widely extend to international well-known manufacturers.

Factory Square Meter	3000 m3	Workshop Equipment	10--Mazak CNC Machine
					6--HEADMAN CNC Machine
					1--of automatic CNC center
Number of employees	105 Workers + 10 officers			4--plain lathe
Number of Engineers	3 designers +2 CAD drawers			4--Press Machine
Number of Inspectors	Raw Material (3)			3--bending Machine
Number of Inspectors			Finish Product (5)	2--Cutting Machine
Testing Equipment	2--Pressure Testing Machine			2-- Chamfering Machine
			1--Surface roughness device	10--Polishing Machine
			2--Spectro Instrument Gun	2--Laser marking Machine

Our Certifications
