Home > Products > Coating Instrument > Adjustable Wet Film Applicator for Paint Stainless Steel Scraper
Adjustable Wet Film Applicator for Paint Stainless Steel Scraper
- 1000 per Month
- T/T Credit Card
Product Description
Adjustable Wet Film Applicator for Paint ,
Magnetic Attraction,Stainless Steel Scraper
| Content: | |||||||||||||||||||||||||
|
Can be used in accordance with ASTM D 823. The Adjustable Wet Film Applicator is an adjustable clearance film applicator. Its extended end plates confine the coating sample during drawdown. The micrometer adjusted gate allows clearance/gap settings from 0 to 3500um increments in 10 micron increments. The applicator consists of two end plates joined by a bridge and an adjustable blade below the bridge. Two micrometers extend through the bridge and contact the upper edge of the blade, allowing it to be adjusted upward or downward to control the gap and ultimately the film thickness. The blade and end plates are constructed of aluminum. The end plates effectively contain the sample pool during the drawdown process. Technical Data.
Comes complete with. Adjustable Film Applicator Storage Box |
|||||||||||||||||||||||||
