AIP171

Brand: YOKOGAWA

Type:AIP171

Origin: the United States

Warranty: 365 days

Colour: new/used

Shipping method: Courier delivery

Module of PLC, DCS, ESD system card, the card is a vibration monitoring system, steam turbine control system module, the advantages of the gas generator spare parts brand: Allen Bradley, BentlyNevada, ABB, Emerson Ovation, Honeywell DCS, Rockwell ICS Triplex, FOXBORO, Schneider PLC, GE Fanuc, Motorola, HIMA, TRICONEX, Prosoft etc. Various kinds of imported industrial parts of our products are widely used in metallurgy, petroleum, glass, aluminum manufacturing, petrochemical industry, coal mine, papermaking, printing, textile printing and dyeing, mechanical, electronic manufacturing, automobile manufacturing, plastic machinery, electric power, water conservancy, water treatment/environmental protection, boiler heating, energy, power transmission and distribution and so on.

DRIVE MODEL NUMBERS AND DESCRIPTIONS Here is a list of the various S200 Series Drives. • VTS – Analog Velocity/Torque Base Drive • SDS – SynqNet option card with Micro-D connectors • SRS – SynqNet option card with RJ-45 connectors • CNS – CAN/Indexer option card (Not documented in this manual) AC Drive Description S20260-VTS S200 120/240 VAC, 1/3-phase, 1.5/4.5 ARMS Base Unit S20360-VTS S200 120/240 VAC, 1/3-phase, 3/9 ARMS Base Unit S20250-VTS S200 120 VAC, doubler/240 VAC 1 ph 1.5/4.5 ARMS Base Unit S20350-VTS S200 120 VAC, doubler/240 VAC 1 ph 3.9 ARMS Base Unit S20660-VTS S200 120/240 VAC, 1/3-phase, 6/18 ARMS Base Unit S21260-VTS S200 240 VAC, 1/3-phase, 12/30 ARMS Base Unit S22460-VTS S200 240 VAC, 3-phase, 24/48 ARMS Base Unit S2xxx0-SRS One of the above drives with optional SynqNet with RJ-45 connectors S2xxx0-SDS One of the above drives with optional SynqNet with Micro-D connectors DC Drive Description S20330-VTS S200 90 VDC, 3/9 ARMS Base Unit S20630-VTS S200 90 VDC, 6/18 ARMS Base Unit S2xx30-SRS One of the above drives with optional SynqNet with RJ-45 connectors S2xx30-SDS One of the above drives with optional SynqNet with Micro-D connectors

BEFORE YOU BEGIN 2.1 SAFETY WARNING READ these instructions before connecting power. Damage can result from MISWIRING at the power terminals. DANGEROUS voltages are present on power input and motor output terminals. Only qualified personnel are permitted to transport, assemble, commission, and maintain this equipment. Properly qualified personnel are persons who are familiar with the transport, assembly, installation, commissioning and operation of motors, and who have the appropriate qualifications for their jobs. Read all available documentation before assembling and using. Incorrect handling of products described in this manual can result in injury and damage to people and/or machinery. Strictly adhere to the technical information regarding installation requirements. Keep all covers and cabinet doors shut during operation. Be aware that during operation, the product has electrically charged components and hot surfaces. Control and power cables can carry a high voltage, even when the motor is not rotating. Never disconnect or connect the product while the power source is energized. After removing the power source from the equipment, wait at least 5 minutes before touching or disconnecting sections of the equipment that normally carry electrical charges (e.g., capacitors, contacts, screw connections). To be safe, measure the electrical contact points to each other and to electrical safety earth with a meter before touching the equipment. 2.2 UNPACKING AND INSPECTING Open the box and remove all the contents. Check to ensure there is no visible damage to any of the equipment. CAUTION Use proper procedures when handling electronic components to avoid damage to equipment. CAUTION Remove all packing material and equipment from the shipping container. Be aware that some connector kits and other equipment pieces may be quite small and can be accidentally discarded. Do not dispose of shipping materials until the packing list has been checked. NOTE Upon receipt of the equipment, inspect components to ensure that no damage has occurred in shipment. If damage is detected, notify the carrier immediately. Check all shipping material for connector kits, documentation, diskettes, CD-ROM, or other small pieces of equipment.
