Fiber Geotextile Cable Tensile Strength Tester Testing Equipment

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Fiber Geotextile Cable Tensile Strength Tester Testing Equipment

Product Description

Introduction

WDW series electromechanical testing machines offer force, displacement or deformation closed loop testing in tension,
compression, flexure, shear, tear and peel etc.
The machine can be equipped with a variety of accessories including: grips, fixtures, compression frames, thermal cabinets and extensometers covering all relevant applications as testing of rubber, plastics, foils, films, textiles, adhesives, paper, foods, foams, timber, wires or other metallic or non-metallic specimens and medical, electronic and other components. The load frames are rigid constructed, providing superior axial and lateral stiffness.

100kn tension testing mahcine 100kn universal testing machine 100kn universal testing machine price 100kn utm 100KN Wire TensileTesting Equipment 100KN wire tensile testing machine

Standards

ASTMA370, ASTME4, ASTME8, ASTME9, ASTM D638, etc.

Specification

Model	WDW-10E	WDW-20E	WDW-30E	WDW-50E	WDW-100E
Structure	column and 2 Ball Screw
Max. Load(kN)	10	20	30	50	100
Tensile space(mm)	670					770	650
Compression space(mm)	900					1000	1000
Host Weight (kG)	370					420	680
Power Supply	220V/50-60Hz
Controller	24 bit AD, external controller
communication mode	USB 2.0
Hand control box	320x240 Display Sscreen，8 key control
Speed(mm/min)	0.01-1000							0.01-500
Displacement resolution	0.4 pm							0.2 pm
Load accuracy	Class 0.5, EN 10002-2 Grade0.5, ISO75001-1 Class 0.5, BS 1610 Class 0.5, ASTM E4, and JIS B7721 Class 0.5
Measuring range	0.2％～100％
strong electric drive system	24V voltage control, with over current overloading protection function
Position limit switch	Upper and lower lights
Power	Power light,leak current protection device
Automatic protection	Overload 10%, automatic protection

Please contact KASON directly for best quotation

Application

This series material testing machine product group was primarily developed for standardized tests on ma- terials and components. Used in conjunction with the intuitive HKtest software. Test Typical: wide range of tension, compression, bending, shearing and low cycle test, include metal, building components, rubber, plastic, spring, high strength steel (HSS), aerospace and automotive structures, screws, nuts,large fasteners, wood products etc.
