JBDW-600CY -60C Low Temperature Cooling Metal Impact Testing Machine

Hst Group Co.,ltd. Gold Verified Supplier

1Yr

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Business Type:

Manufacturer

Year Established:

2009

Factory Size:

1,000-3,000 square meters

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

JBDW-450CY -60C Low temperature cooling Impact Testing Machine

Main configuration

1. Capacity:

300J

2. Application

JBDW-CY Computer Control automatic Charpy Impact Testing Machine is used for measuring

the metal material resistance performance under dynamic load,in order to determine the material

properties under dynamic load.

It’s a necessary testing machine,not only used in the metallurgy,machine manufacture etc areas,

but also used for the science research.

3. Standards:

ASTM E23, ISO148-2006 and GB/T3038-2002, GB/229-200,ISO 138,EN10045.

4. Main Technical Specifications:


Model	JBDW-300CY	JBDW-450CY	JBDW-600CY	JBDW-750CY



Max. impact energy(J)	300	450	600	750
Pendulum Torque	160.7695	241.1543	321.5390	401.9238
The distance between the pendulum shaft and impact point	750mm
Impact speed	5.24 m/s
Raised angle	150°
Round angle of the jaw	R1-1.5mm
Round angle of impact edge	R2-2.5mm,R8±0.05mm
Angle accuracy	0.1°
Cooling way	compressor
Capacity of sample box	20
Range of low temperature	room temperature --80°c
Standard specimen dimension	10mm×10(7.5/5)mm×55mm
Power supply	3phs, 380V, 50Hz or specified by users
Net Weight (kg)	900
Low temperatrue	room temperature to -40c, -60c, -80c, -100c, compressor cooling
