Home > Products > CNC MILLING MACHINE > XK7114 small size CNC milling machine for metal cutting

XK7114 small size CNC milling machine for metal cutting

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Description

Features:

Mini hobby CNC mill machine with servo spindle motor;

Designed for hobby, household and factory use;

Rigid tapping available

Specification	XK7114
Worktable size	200x600mm
X axis travel	350mm
Y axis travel	240mm
Z axis travel	310mm
T slot	12x45mm 4
Max.loading of worktable	50kg
spindle taper	R8
spindle speed	4000mm/min
Distance from spindle center to column	268mm
Distance from spindle nose to worktable surface	38-348mm
Main motor(Frequency motor)	750W
Feeding motor(step motor)X/Y/Z	6Nm/6Nm/6Nm
Fast raip speed	4000mm/min
feeding speed	0-3000mm/min
min set unit	0.001mm
Net weight	580kg
Machine size	148/130/185cm
