High Precision Mini Slant Bed CNC Lathe Machine CK36L for Metal Threading with CE

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Description

Products Recommend

Products Description

Slant Bed CNC Lathe Main Features:

1. Mini lathe cnc machine for slant bed 45 degree.

2. X/Z axis for Taiwan precision ballscrew and Taiwan linear guideway.
3. GSK,Siemens and Fanuc CNC controller for choices.

Model	CK36L
Max. swing over bed	φ360mm
Max. swing over carriage	φ210mm
Max. cutting legth	500/750mm
Rail width	284mm
Spindle nose	A2-5,A2-6
Spindle bore	φ56mm,(62mm)
Taper of spindle bore	1:20
Chuck	6" , ( 8")
Range of spindle speed	150-4200rpm
X axis travel	210mm
Z axis travel	500/750mm
X/Z rapid speed	20/20m/min
Hydraulic turret	8
Max. section of tool	20*20mm
Stroke of tailstock sleeve	80mm
Diameter/ Hole of tailstock sleeve	φ60mm/MT4
Main motor power	5.5KW/7.5KW
Coolant pump power	370W
Overall dimensions LWH	2630/291015501750mm
Packing size LWH	2830/313017502150mm
N.W/G.W	2700KG/3000KG

Standard Accessories:

· Spindle unit · Pneumatic or hytraulic chuck · AC servo motor · Hydraulic turret · Auto lubration coolant system

Optional Accessories:

· With milling or drilling power head · Automatic chip removal

Detailed Images

Company profile

Customers' Feedback

FAQ

Q1: How is the warranty? A1: Warranty time is 13 months after BL date. Q2:Can we visit your factory before order? A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking. Q3:Do you have a stock? A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs. Q4:What’s the MOQ? A4:One set only. Q5:How about your quality? A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services. Q6:Do you have professional engineers? A6:Yes.we have professional engineers and designers. We can provide OEM services. Q7:Can you provide customized machines? A7:Yes, we can design and manufacture according to your specific requirements.
