CM6241 410mm Gap Bed lathe machining manual metal Turning Lathe machine

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Description

Metal Horizontal Gap Bed Turning Lathe CM6241 Main Features:

1. Super voice frequency heated bedwaysHardened and grounded gears in the headstock;
2. With 2 precision D degree taper roller bearings on the spindle;
3. Integrated deluxe cast iron floor stand;
4. Tolerance test certificate, test flow chart included.

Specification	CM6241×1000 /1500mm
Swing over bed	410mm
Swing over cross slide	255mm
Swing in gap	580mm
Length of gap	19mm
Distance between centers	1000mm /1500mm
Center height	205mm
Width of bed	250mm
Spindle nose	D1-6
Spindle bore	52mm
Taper of spindle bore	MT6
Range of spindle speed	16 changes 45-1800r/min
Travel of compound rest	102mm
Max.travel of cross slide	210mm
Leadscrew pitch	4T.P.I.
Max.Section of tool	20×20mm
Longitudinal feeds range	0.05-1.7mm/rev(0.002-0.067/rev)
Cross feeds range	0.025-0.85mm(0.001-0.0335/rev)
Cross feeds range	0.025-0.85mm(0.001-0.0336/rev)
Inch threads range	45kinds 2-72T.P.I
Diametrical pitches range	21kinds 8-44D.P.
Module pitches range	18kinds 0.3-3.5M.P.
Dia.of tailstock sleeve	50mm
Travel of tailstock sleeve	120mm
Taper of tailstock sleeve	MT4
Power of main motor	2.2/3.3kw(optional 3.0/4.5kw)
Power of coolant pump	90w
Overall dimension	1940/2440×850×1300mm
Packing size	2060/2560×900×1640mm
N.W/G.W	1500/1750kgs 1550/1800kgs

Detailed Images

Recommend Products

Company Profile

Professional Service

FAQ

Q1: How is the warranty?

A1: Warranty time is 13 months after BL date.

Q2: Can we visit your factory before order?

A2: Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.

Q3: Do you have a stock?

A3: Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.

Q4: What’s the MOQ?

A4: One set only.

Q5: How about your quality?

A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.

Q6: Do you have professional engineers?

A6: Yes, we have professional engineers and designers. We can provide OEM services.

Q7: Can you provide customized machines?

A7: Yes, we can design and manufacture according to your specific requirements.
