Horizontal metal electric small planer machine BC6063 mini shaping machine

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Product main features:

1. Shaper workbench can about rotational angle worktable moving structure with lateral and lifting; to planing inclined plane,thereby expanding the scope of use.
2. Feed system of shaper with a cam mechanism, adjust the feed quantity. Change the amount of knife, very convenient.
3. Shaper in knife system overload safety device is installed, when due to careless handling or by external influence and cutting overload when, take the knife itself slipping, nondestructive parts which guarantees the machine to normal operation.
4. The sliding pillow and bed rails and with speed gear pair and the main rail sliding surface, lubrication oil pump has played for circulating lubrication.
5. Shaper with parking brake mechanism, so the speed of transformation. When starting machine tools and parking, the power supply can not be cut off.

Specification	BC6063
Maximum planing length	630mm
Maximum distance from the bottom of the working table	385mm
lateral travel	630mm
Vertical stroke	360mm
Tool frame travel	120mm
Sleeper reciprocating times (per minute)	14/20/28/40/56/80
Main motor power	3W
The maximum size(width*thickness)of the handle	20×30mm
The size of the T groove in the center of the worktable	18mm
Angle of rotation	±60°(toolpost)
Workbench size	630×400/660×400mm
Shape size	2000×1300×x150mm
Machine tool weight (about)	1750/1870KG
Package dimensions	2000/1300/1650mm
