Linear Scale & optical encoders & Grating Ruler Supplier

Name: Linear Scale & optical encoders & Grating Ruler Supplier
Brand: HanDing
Availability: InStock

FOB Price

CNY 350 - 360 / Set

10 Sets(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HanDing		Place of Origin	China
Model Number	XF series

Product Description

Model	XF1	XF5	XE1	XE5	FS1	FS5
Grating sensor	20μm(0.020mm),10μm(0.010mm)
Grating measurement system	Transmission infrared optical measurement system, infrared wavelength: 800nm
Readhead Rolling System	Vertical five-bearing rolling system
Resolution	1μm	5μm	1μm	5μm	1μm	5μm
Effective range	50-550mm		50-1000mm		50-400mm
Working speed	20m/min(1μm),60m/min(5μm)
Out signal	TTL,RS422,-1VPP,24V
Operating Voltage	5V±5%DC/12V±5%DC/24V±5%DC
Working environment	Temperature:-10℃~45℃ Humidity:≤90%
