Home > Products > temperature & humidity > humidity temperature controller WHD72-11 ACREL panel Mounted Temperature & Humidity Controller

humidity temperature controller WHD72-11 ACREL panel Mounted Temperature & Humidity Controller

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Specification

WHD series smart temperature and humidity controller is suitable for adjustment and control of temperature and humidity in equipments of high voltage switchgear, terminal box, ring network panel, box transformer substation etc. It can effectively protect relevant equipment from faults resulting from excessive low or high temperature, creepage or flashover etc.from humidity or condensation.

Accuracy

Temperature ±1℃
Humidity ±5%RH

Consumption
Auxiliary power supply
Basic power consumption(≤0.8w)
Relay power consumption(each channel≤0.7w)

Installation:
Panel mounted

Dimension(L*W*H)：
Pannel size (L×W): 75*75mm

Cutout size (L×W): 67*67mm
Housing (L×W×H): 66*66*92mm

Typical Nework

Technical Parameter

Wiring&Installation

Exhibition

company introduction

Acrel Co., Ltd. [Stock Code : 300286. SZ] is a high-tech enterprise concentrating on research, production, sales and services. It mainly provides systemic solutions of energy efficiency management and electrical safety for users. ‘Acrel’ is equipped with the complete production lines from cloud platform software to sensors. Until now, it has more than 8000 sets systemic solutions used in China to help users to realize energy visual management ,supply energy data services and improve electrical efficiency and safety. ‘Acrel’ has maintained steady growth since its listing in 2012. The company will adhere to the concept of‘innovation,high-efficiency,unity and honesty’ and it provides more high-quality solutions,products and service for power system users and micro-grid..

Payment & Delivery

1.Payment: T/T 100% in advance, credit card, western union, in cash and etc. T/T 30% as deposit and the balance before shipment or against copy of B/L is acceptable with enough MOQ.

2.Delivery Arriving Time: in 3-7 working days after payment received.

3.Ways of Delivery: By sea, air, train or international courier like Fedex, TNT, DHL and UPS.
