Spot sale of Tektronix DPO7104 digital fluorescence oscilloscope

Tektronix DPO7104 1GHz Fluorescent Oscilloscope's unparalleled performance and versatility - Deeper analysis of your design

Enable you to complete work faster

The Windows XP operating interface simplifies the steps of storing wave patterns and creating files.

Built in high specification PC Base.

3.5 GHz DSP bandwidth enhancement and 2.5 GHz hardware analog bandwidth.

The sampling rate can reach up to 40 GS/s.

Memory length up to 40 M (can be paired with the record length option of 10RL to reach 400 M).

The Tektronix DPO7104 1GHz fluorescence oscilloscope has a waveform update rate of up to 250000 wfms/s.

My scope can set the most commonly used oscilloscope functions on the desktop, without having to memorize a bunch of oscilloscope operation methods.

Right Click allows you to control various functions of the oscilloscope with the right mouse button, combined with the shortcut menu, to simplify the operation of the oscilloscope.

OpenChoice software allows you to customize your own testing and measurement with familiar analysis tools.

Up to 1440 triggering modes, sufficient to meet both predictable and unpredictable debugging needs in your work.

Model oscilloscope bandwidth oscilloscope sampling rate recording length channel

DPO7354 3.5 GHz 40/20/10 GS/s 500/250/125 M 4

DPO7254 2.5 GHz 40/20/10 GS/s 500/250/125 M 4

DPO7104 1 GHz 40/20/10 GS/s 250/125/50 M 4

DPO7054 500 MHz 20/10/5 GS/s 250/125/50 M 4Tektronix DPO7104 Fluorescent Oscilloscope The industry's largest XGA touch screen display with a 12.1 inch screen.

FastAcq capture mode can accelerate debugging work by clearly displaying incomplete signals through patented DPX ® Capture technology uses a waveform update rate of 250000 times per second to identify unpredictable bursts and other rare events.

Pinpoint ™ The trigger system uses silicon germanium (SiGe) technology to provide trigger sensitivity of equivalent instrument bandwidth for all trigger types on A and B trigger circuit boards. It can capture very narrow bursts with very small trigger jitter. Pinpoint ™ Triggering can provide a complete set of advanced trigger types on both A and B.

The triggering functions such as I2C, SPI, and RS-232 are all standard functions. The DPO7000 also has built-in analog HDTV/EDTV and other emerging triggering functions, and can also choose to purchase CAN triggering functions.

Built-in various advanced waveform analysis tools, 53 automatic measurement parameters, including data statistics function, can display up to 8 types on the oscilloscope screen simultaneously

Multiple standard communication interfaces RS-232, LAN, GP
