Lamp 3mm Round Bi-Color led
Negotiable
/ Piece
10000 Pieces(Min.Order)
- 1000000 Piece / Pieces per Month
- T/T L/C D/P D/A Credit Card PayPal Cash Escrow Other
You May Like
Product Details
| Brand Name | SSHX | Place of Origin | China | |
| Model Number | LR3WYC*** | Certification | ROHS | |
| Power | Other | Storage Temperature(℃) | , | |
| Operating Temperature(℃) | , | Emitting Color | Other, Bi-Color | |
| Chip Material | AlGaInP |
Product Description
Product Parameters
1-1 Electrical / Optical Characteristics at Ts=25°C
| Item | Symbol | Test Condition | Value | Unit | ||
| Min. | Typ. | Max. | ||||
| Luminous Intensity | IV | IF=20mA | Y: 60 | — | 190 | mcd |
| YG: 40 | — | 120 | ||||
| Dominant Wavelength | λd | IF=20mA | Y: 585 | — | 595 | nm |
| YG: 570 | — | 575 | ||||
| Forward Voltage | VF | IF=20mA | Y: 1.7 | — | 2.4 | V |
| YG: 1.7 | — | 2.4 | ||||
| Viewing Angle | 2θ1/2 | IF=20mA | — | 120 | — | Deg |
| Reverse Current | IR | VR=5V | Y: — | — | 10 | μA |
| YG: — | — | 10 | ||||
1-2 Absolute Maximum Ratings at Ts=25°C
| Parameter | Symbol | Rating | Unit |
| Power Dissipation | Pd | 60 | mW |
| Forward Current | IF | 20 | mA |
| Peak Forward Current | IFP | 50 | mA |
| Reverse Voltage | VR | 5 | V |
| Operating Temperature | Topr | -40～+85 | ℃ |
| Storage Temperature | Tstg | -40～+100 | ℃ |
Notes：
1. 1/10 Duty cycle, 10ms pulse width.
2. The above forward voltage measurement allowance tolerance is ±0.1V.
3. The above color coordinates measurement allowance tolerance is ±0.005.
4. The above luminous intensity measurement allowance tolerance ±10%.
