Home > Products > Mud Agitator > Mud Agitator ,18.5KW mud mixer ,NJ18.5-KF97 Mud Agitators for Mud Tank

Mud Agitator ,18.5KW mud mixer ,NJ18.5-KF97 Mud Agitators for Mud Tank

FOB Price

USD $1 - $4000 / Set

1 Set(Min.Order)

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:	Zhenghang	Place of Origin:	China	Model Number:	ZHNJ-5.5 , ZHNJ-7.5 , ZHNJ-11 , ZHNJ-15, ZHNJ-18.5
Certification:	IEC ,ATX，	After-sales Service Provided:	No overseas service provided	Warranty:	12 mounth
Dimension(LWH):	1158x840x655mm	Condition:	New	Product Type:	Other, driilling Mud ,slurry,mire,lama,slip
Voltage:	380V，400V，440V，460V，480V, 600V，660V	Application:	Liquid with Suspended Solids	Power(W):	5.5KW，7.5KW，11KW，15KW ,18.5KW
Additional Capabilities:	Other, Adopting inclined blades, the mixing effect is excellent. The stirring intensity is high, the range of influence is wide, and the starting resistance is reduced.	Mixer Type:	Agitator

Mud Agitator ,18.5KW mud mixer ,NJ18.5-KF97 Mud Agitators for Mud Tank

Motor power Мощность электродвигателя	5.5Kw	7.5Kw	11Kw	15Kw
Power supply Источник питания	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ
Impeller speed Скорость вращения крыльчатки	73 r/min	73 r/min	73 r/min	73 r/min
Impeller diameter Диаметр крыльчатки	￠600 mm	￠750￠650 mm	￠800/￠700mm	￠1000/700mm
Weight Вес	300kg	320kg	410kg	460kg
Overall dimension Размер	1050×600×590 mm	1150×600×600 mm	1300×660×600mm	1400×660×600mm

Zhengzhou Hangyu Explosion-proof Motor Co., Ltd.: Contact nameJenny QI; Phone86-1772-4846377; AddressShangjie Zhengzhou,Henan
