4.5kw dual power diesel generator 5kw dual voltage diesel generator

Name: 4.5kw dual power diesel generator 5kw dual voltage diesel generator
Brand: Belon Power
Price: $450 - 470 / Set

FOB Price

450 - 470 / Set

20 Sets(Min.Order)

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Model	DG6500LE-3D
Frequency[Hz]	50 60
Voltageg[V]	220.230.240.110/220.115/230.120/240.230/380.230/400.240/415
Voltageg[V]	220.230.240.110/220.115/230.120/240.230/380.230/400.240/415
Rated Power( KW)	Single phase 4.0/Three phase 4.5 Single phase 4.5/Three phase5.0
Max. Power(KW)	Single phase4.5/Three phase5. 0 Single phase5.0/Three Phase 5.5
Rated Output Current（A )	Single phase 17.4/Three phase6.5 Single phase19.5/Three phase7.2
DC Output	12V 8.3A
Phase	Single/Three Phase
Excitation Method	Brush self-excitation
Power FactorΦ	1.0(0.8)
Insulation Class	F
Fuel Tank Capaciity[L]	12.5
Engine Model	186FA
Start Method	Electric start
Engine Type	Single cylinder,4 stroke,air-cooled, vertical
Bore*Strokke[mm]	86*72
Displacement	0.418L
Compression Ratio	19.5：1
Speed[rpm]	3000 3600
Power [Kw]	5.8 6.6
Oil Capacity[L]	1.65
Fuel Consumption[g/kwh]	≤275 ≤280
Fuel No.	Diesel: 0#(Sumner), -10#(Winter) Use No. 0 diesel in summer, and use No. -10 or No. -20 diesel in winter.
Oil No.	SAE10W30 (CD grade or above) uses CD or above grade 15W-40 oil (or SAE equivalent grade oil)
Optional	ATS
	Remote Control
	Intelligent digital display panel
Size [mm] (LWH)	R720485615/25mm S700485600/ 35mm S 740505620
Packing Size [mm] (LWH)	R740500635/25mmS 710500620/ 35mmS760515630
Net Weight/Gross Weight[Kg]	R106/25mm S112/35mmS118 R109/25mmS/115/35mm S121
