Home > Products > Multi-Function welding machine > DENOH Multi-function welding machine/Mig Welding Machine
DENOH Multi-function welding machine/Mig Welding Machine
- 100 Set / Sets per Month
- TianJin
- T/T L/C Other
- 5 days
- MIG inverter welder Multi Function Welding Machine for Metal Sheet
- DENOH HW230 Engine welding machine
- Portable Generators Small Diesel Generator Diesel Engine Driven Welding Machine
- Good Quality engine driven welders Engine Driven Welding Machines
- Open Type Electric Start Portable Used Diesel Engine Welder
- Engine Generator and Best Welding Machine for Home Use
Product Details
Brand Name: | DENOH | After-sales Service Provided: | Engineers available to service machinery overseas | Usage: | Pipeline welding,Various welding work |
Product Description
Engine welding machine
This is advertisting for DENOH Seimitsu Welding equipment.Please don’t place order directly.If you need this kind equipment, please contact us for machine detail function and performance first.
1. Multi-function welding machine that could meet flux core gas shielded welding,flux core self shielded welding,MIG/MAG welding,pulse MIG/MAG welding.
2. The DPS chip is control core of the control system.Taking BUCK(Chopped wave) circuit as power platform.The current wave shape is totally controlled by software.The system has high flexibility and dynamic response performance.It is fundation of welding and heat input accurate controlling.Combining with welding trolley digital control wire feeding system can ensure the pre-programming and online adjustment to wire feeding speed.So that achieving real time controlling to welding process.
3. Patent:202010284140.1,It not only meet the demand of present manual electric arc welding and flux core semi-auto welding function,but achieving pulse GMAW high quality automatic welding function.It is also compatible 2 power supply mode of DC low voltage electricity generation and 3-phase 380V AC power grid supplying.Greatly improving the adapatability the welding operations to enviroment,field and operation mode.
4. The controlling interface had digital communication port and ananlogue port.Can using for connecting automation special machine or welding robot.
5. The current adjustable range is extremly wide because of Chopped wave components’ fully control charateristic.Compared with invert technich,Chopped wave directly facing load for adjusting.Duty cycle can be adjusted stablely from 0.5%-100%.The response speed is fast,and has low impact on load.
6. The purpose of high frequency pulsating current is for adjusting discrepancy of current mean and effective values.So the frequency is higher,gernerally it is over than 20kHz,This welding power supply adopts 35kHz,At this point, the current pulsation has less disturbance on the movement of the molten pool and the transfer of droplets
7. During welding process,current pulse frequency keep stable.Adjusting current mean and peak value instantly.Do allocation of electric arc and arc length adjusting through the factors of pulse current frequency,pulse current amplitude,pulse current duration time etc to realize the control of heat input
HW500E DGN Multi-Function welding machine | ||
DC rated input voltage/current | V/A | DC50-90V/350A |
AC rated input voltage/frequency | A | AC380V±15%/50-60Hz |
kVA | 30 | |
Rated input current | A | 45.6 |
Rated output voltage | V | 39 |
Rated load duration rate | % | 60 |
V | 50-90 | |
CC mode output current range | A | 45-500 |
CV mode output voltage range | V | 10-39 |
Wire diameter | mm | 0.8,1.0,1.2,2.0 |
Carbon steel,stainless steel,flux core | ||
Wire feeding type | Push wire | |
Gas flow | L/min | 15-25 |
Cooling method | Air cooling | |
IP23 | ||
Insulation grade | H | |
610*320*420 | ||
Weight | kg | 39.5 |
Accessories package size(L*W*H) | mm | 610*320*275 |
Accessories package weight | kg | 38.5 |
High-Performance Inverter Technology: The TIG Pulse Welding Machine boasts advanced inverter technology, ensuring efficient energy conversion and stable arc performance. This results in a smoother, more precise welding experience, ideal for intricate and delicate work.
Versatile Applications: Suitable for a wide range of welding tasks, including pipeline welding and various other welding projects. Its adaptability makes it a must-have for any workshop or construction site.
User-Friendly Interface: Equipped with a clear and intuitive control panel, the machine allows for easy adjustments to settings, ensuring that users can quickly find the optimal welding parameters for their specific needs.
Input Voltage: AC 220V/380V, ensuring compatibility with various power sources.
Output Current Range: DC 5-500A, offering a wide range of output capabilities to handle different materials and thicknesses.
Duty Cycle: 60% at 500A, providing consistent performance even under prolonged use.
Protection Features: Overload, over-voltage, and short-circuit protection to safeguard the machine and the operator.
CE Certified: Meets stringent safety and health protection standards, ensuring a safe working environment.
After-sales Service: With engineers available to service machinery overseas, you can trust DENOH for prompt and reliable support wherever you are.
Quality Assurance: DENOH is committed to delivering products that meet the highest quality standards, backed by a range of production certifications including ISO9001, ISO9000, ISO14000, and TS16969.
Wide Distribution Network: DENOH's products are available in North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, and the Domestic Market.
For more information or to discuss your specific welding needs, please feel free to reach out to our dedicated overseas sales team:
Name: Cinda
Position: Overseas Sale
WhatsApp: 8613811582983
Company Phone: 86-010-61445155
Mobile Phone: 86-13811582983
Company Address: Shunyi
DENOH Industrial DC TIG Pulse Welding Machine Inverter Welder TIG MMA Welder is more than just a tool; it's a partnership in precision and reliability for your welding projects. Experience the difference with DENOH today.
