4-layer high thermal conductivity thermoelectric separation thick copper aluminum base

Product application: Automotive products

Board: Caierde PP+Caierde Aluminum+Beige Aluminum,

Minimum aperture: 0.55mm

Layers: 4 layers, thick copper aluminum substrate with thermal conductivity and thermoelectric separation

Minimum line width: Inner layer 10mm

Minimum line width: outer layer 10mm

Minimum pore copper: 25um

Minimum laser hole/

Finished copper: inner and outer layer 8.0OZ

Pressure resistance: 2000Pa

Thermal conductivity 8W

Finished product thickness 1.75mm

Shipping size: 152 * 266mm

Surface treatment: lead-free tin spraying
