Domestic graphite engraving machines Domestic graphite engraving machines S-1000G

X/Y/Z Travel:   1000*820*350mm

Worktable Dimensions:   1020*820mm

Worktable Load Capacity:   800Kg

Spindle Face to Worktable Height:   95--445mm

Positioning Accuracy:   +-0.005/300mm

Repeatability:   +-0.003/300mm

Tool Magazine Capacity:   24.0

Spindle Speed:   24000--40000rpm

Moving Speed:   24m--36m/min

Cutting Speed:   10m--20m/min

Tool Change Time:   2 seconds

Machine Tool Dimensions:   2700*2300*2600mm

Machine Tool Weight:   5200Kg

Control Method:   Fully closed--loop control

Torque:   Customizable configuration

Drilling Capacity:   Customizable configuration

Voltage:   380V

Frequency:   50/60 Hz

Phase Type:   3--Phase Electricity

Type of Milling Machine:   Gantry

Color:   Black

Machining Centre:   Horizontal

Automation Grade:   Automatic

Job Material:   Graphite

Usage/Application:   Graphite Processing|Carbon Fiber Processing|Ceramic Processing|Composite Material Processing

Can it be customized:   Supports customization

Guarantee:   One year warranty for the whole machine

Brand:   ShangshanJingji

None:   None

The Domestic Graphite Engraving Machines are designed to provide exceptional precision and efficiency in machining a wide range of graphite materials. These machines are particularly well-suited for the production of intricate and complex graphite components such as electrodes, molds, and boats. Featuring advanced CNC technology, the machines offer high-speed engraving capabilities with remarkable accuracy, making them ideal for industries like electronics, aerospace, and manufacturing. Equipped with the ability to handle isostatic isotropic graphite, they ensure superior cutting performance, especially when processing wear-resistant graphite boxes or fine-tuned parts. The machines are also optimized for automatic lathe turning graphite, allowing for smooth, consistent results with minimal setup time and operator intervention.

For companies seeking tailored solutions, the Customized Graphite CNC Machine Tool offers a highly versatile platform that can be adjusted to meet specific manufacturing needs. One of the standout features of these machines is their integration with a Five-Axis Vertical Milling Machining Center, which allows for multi-dimensional machining with precision and efficiency. This setup ensures that even the most complex graphite shapes can be created with ease, whether it's the processing of graphite round rods or the outer circle of a graphite component. The combination of these advanced technologies results in a reliable and flexible solution for manufacturers looking to streamline their graphite processing operations while maintaining high standards of quality and precision.
